Jul 28, 2013

HyRel 3d printer printing with Sugru, Play-Doh, Plasticine and Air-Dray Modelling Clay

HyRel is 3d printer in pre-sales pre-order phase. Their youtube chanell shows printer printing with various materials. Sugru is most interesting one.

This is the simplest E1 version, E5 comes with four printheads.

Protos v2 3d printer

Priced at 799 € ...

Nothing extraordinary to report here ...

STATUS 3d printer


  • Depth: 400 m/m.
  • Width: 520 m/m.
  • Height: 370 m/m.
  • Weight: 15,0 Kg.
  • Work volume: 205x205x205 m/m.
  • X and Y axis resolution: 0,2 m/m.
  • Z axis resolution: 0,125 m/m.
  • Extrusion material: ABS 1.75 mm.
  • Average print speed: 50 mm/s
  • Control software: Replicator G.

3D printer manufactured with our exclusive 15x15mm aluminium profile. It is formed by a structural base and a bridge for holding the Y and Z axis.
  • Innovative patented extrusor head
  • Closed toothed dragging Belt.
  • Easy belt tensiĆ³n set.
  • Quick axis calibration based on closed belts system.
  • Stiff structure.
  • Absence of movements and vibrations during operation.
  • Bearing on polish aluminium profile in the 3-axis.
  • No manteinace, thanks to its autolubricated bearing.
  • Fleasibility to hold several control boards.
  • Hide wiring.
  • Wiring in movement guided by cable trays.
  • Base over adjustable height rubber pads, allowing a perfect level.

Opencube Scoovo C170 3d printer

New 3d printer from Japan. I couldn't find English version of the page or more detailed product description.

Witbox Helios 2X 3d printer

Another day another filament 3d printer ...

Tech specs:

-Ramps 1.4. , Arduino Mega 2560.
-LCD screen with navigation knob. , Pines D4/D5 expansion adapter (double centrifugal fan)
-Option warm bed: Helios or Prusa.
-220V Input Power 12V 29A Ouput 348W. , Termisores 100k in bed and extruders.
-12V 40W resistors.
General Mechanical- blued steel-frame black.
-bars for trucks Ina X, Y, Z
-Caps Igus For X, Y, Z.
-ch Igus for the passage of cables.
-Spindle Igus for Z axis will link to Flexible engine.
-Piezerio, trucks, wheels, etc ... black blued steel. leveling-bed system with 3 points and cushioning. , quick-change system work surface.
Mechanical Extruder -Option: double or single extruder "simple option comes fully wired for future expansion." fast-change system in extruders, with Molex connection in the car. , quick-change system thread. Extruders-aluminum- , new design.
-0.4mm nozzles. -piece cooling nozzles. , fans and heat sink.
 -Dimensions -Area Y200mm Z200mm x200mm working -Foreign Total Length 505 Width 366 Height 450. Materielaes -PLA -ABS -PVA (Developing) NYLON (Developing) Resolution of layers
-default Preset. -High 0.1 mm -0.2 mm Medium -Low 0.3 mm
Securities community-Certificate European CE -Safety door. Software -Firmware Marlin preconfigured. -Host WITsoft (in development) -compliant Host Repetier, Ponterface, Cura, ReplicatorG. -Slic3r (recommended and default) -Skinforce Communications -SD card reader and card 4Gigas included. -USB port.
Various mounting-Option hive with several printers, assembled and anchored on each other and can stack up to 3 heights, avoiding having to mount additional shelves. -inspired System Fibonacci curve with teflon tube for the passage of thread. Through this innovative power tubes are completely thread into the machine, taking care of the aesthetics of the product and ensuring minimal friction.

Ford Shifter

Looks like Ford is full into 3d printing. This is interesting little projects of 3d printed active haptic feedback shift stick.

InfraStructs - embedding data in 3d printed objects

Embedding codes in internal structure of 3d printed object which can be scanned with tetraherz imaging technology.

Here are similar technologies:

I also remember that there was a post about similar DIY project but I just can not find it ...

ProJet 1500

High end color (personal) professional 3d printer for the rest of us. Ya right at 14 500 USD. Those prices need to drop!

Jul 27, 2013

Suspended deposition 3d printing technology

Robotic hand injecting light curing material in gel block. It has "undo" option and can utilize 3D vector-based toolpaths.

Suspended Depositions from BrianHarms on Vimeo.
This project aims to blur the line between processes of design and fabrication in the context of rapid prototyping by increasing the fluidity of the fabrication process through coordinated material and robotic processes. The project exploits feedback loops that allow the process to be used as a live generative form-finding tool as well as a method for reification of designed objects.

By injecting and suspending light-curing resin in a gelatinous medium, one is afforded the ability to shape freeform objects without the need for molds or other subtractive manufacturing processes that would otherwise be necessary. The gel acts as an omnidirectional support material which is reusable, so there is no wasted material.

One major distinction between this project and other rapid prototyping processes is the ability to utilize 3D vector-based toolpaths. Virtually all other processes use paths generated via contouring a digital model, and rely on the hardening of each successive layer before being able to move on to the next.

The suspension of resin in space without added support material allows for the ability to navigate and fabricate directly on and around other existing objects within the Gel, as well as the ability to observe the process from any angle. The suspension of time in this process allows for tool changes, manual injections, on-the-fly robotic injections, multi-material injections, live modification of the digital or physical model, and the ability to physically "undo" (resin removal via suction or scooping).

Special thanks to Peter Testa, Brandon Kruysman, Jonathan Proto, Devyn Weiser, and Kyle and Liz Von Hassln.

SCI-Arc Fall 2012
Testa Vertical ESTm Studio
Instructor: Peter Testa / Brandon Kruysman / Jonathan Proto
AT: Peter Vikar
Project Leader: Brian Harms (
Project Team: Haejun Jung / Vince Huang / Yuying Chen

Music: "Baalbek" by Trifonic.

Suspended Depositions - Process from BrianHarms on Vimeo.
An overview of the stages of the project. This is the first attempt at injecting a hemi-sphere into a container of gel using vertical contours.

Disney researches 3d printed mechanical characters

Soon in toy store near you ...

From project site:
We developed an interactive design system that allows non-expert users to create animated mechanical characters. Given an articulated character as input, the user iteratively creates an animation by sketching motion curves indicating how different parts of the character should move. For each motion curve, our framework creates an optimized mechanism that reproduces it as closely as possible. The resulting mechanisms are attached to the character and then connected to each other using gear trains, which are created in a semi-automated fashion. The mechanical assemblies generated with our system can be driven with a single input driver, such as a hand-operated crank or an electric motor, and they can be fabricated using rapid prototyping devices.
We demonstrate the versatility of our approach by designing a wide range of mechanical characters, several of which we manufactured using 3D printing. While our pipeline is designed for characters driven by planar mechanisms, significant parts of it extend directly to non-planar mechanisms, allowing us to create characters with compelling 3D motions.

Ghost Host - 3d printed scales for Atwood Ghost pocket tool

Atwood pocket tools and knives have cult following and collecting community.  One of them decided to design and print custom scales with pocket clip for Ghost G1 model (called Ghost Host), upgrading it and making it more usable.


3d printed toilet paper holder

... and it comes with quick change function ... now THAT is a work of a genius!

3d printed couples rings

Awwwwwww ... this is sooo sweeet ... or: How to make plastic cherishable.

MY Reason Your Ring from Christopher Scott on Vimeo.
My Reason Your Ring is a celebration and reflection of why couples are together. Using contemporary 3D printing technologies, an accessible and democratic material, My Reason Your Ring evolves what is cherishable about the objects from monetary to relational as only one partner has the ability to print the ring for the other through the reason for their relationship that they choose as a password. Because of the nature of the material, the rings can be truly lived in; lost on a picnic, scratched, faded in the sun, dropped in the ocean, etc., only to be replaced by one’s partner. The rings are designed as inverses where the volume on one becomes the void on the other, becoming unique symbols for the couple.

Jul 26, 2013

VIA (Visual Impairment Aid)

Wow! What an amazing project! Kudos Mr. Mizchief100!

From project page:

This project was my take on a DIY visual impairment aid that uses haptic and sound feedback. Basically it uses a distance sensor to measure how far objects are from it and then it beeps/vibrates accordingly (far away is slow vibrate/long beep delay and close up is fast vibrate/quick beeps). The difference between this project and others is this project uses one distance sensor (as opposed to many) to make feedback more specific and simpler to interpret, use of both haptic and sound feedback, the mounting of the device under the arm and not attached to the hand (keeps it free to feel where you're going and use for daily tasks), and a few simple control buttons on the case (I also put the word for each button in braille next to them). What I really like about the design is how compact and sturdy it is. I wore it around for a few hours to get used to it and found it didn't hinder too many of my daily activities (I found it fit in sleeves too!).

Complete build guide:


here is another projects that generates 3d printable Braille signs from text for the blind:


3d printable cane for visually impaired:

Tutorial on external and internal 3D printed support

Another great tutorial from BusyBotz about external and internal support on 3d printed objects.

Introducing the UP Mini 3d printer

Jul 25, 2013

Make It Stand - balancing 3d models

Software that makes your models stand. It adjusts shape - pose - weight balance without the need for heavy bases or magnets. There is no download of the software I can find, hopefully it will show up somewhere. The paper explaining science and calculations behind it is available so maybe it can be interdependently programmed.

Research abstract:

Imbalance suggests a feeling of dynamism and movement in static objects. It is therefore not surprising that many 3D models stand in impossibly balanced configurations. As long as the models remain in a computer this is of no consequence: the laws of physics do not apply. However, fabrication through 3D printing breaks the illusion: printed models topple instead of standing as initially intended. We propose to assist users in producing novel, properly balanced designs by interactively deforming an existing model. We formulate balance optimization as an energy minimization, improving stability by modifying the volume of the object, while preserving its surface details. This takes place during interactive editing: the user cooperates with our optimizer towards the end result. We demonstrate our method on a variety of models. With our technique, users can produce fabricated objects that stand in one or more surprising poses without requiring glue or heavy pedestals.

3D printed ink jet printer cartridges

This could be useful ... I know some inkjets won't work without original verification chips on cartridges. hmmmmm ... looks cool anyway ...

3D printable PCB mill - Cyclone PCB Factoy

Jul 21, 2013

3D Printers Shown To Emit Potentially Harmful Nanosized Particles

Let the fear-mongering begin!

An anonymous slashdot reader writes:
"A new study by researchers in the Built Environment Research Group at the Illinois Institute of Technology shows that commercially available desktop 3D printers can have substantial emissions of potentially harmful nanosized particles in indoor air. Many desktop 3D printers rely on a process where a thermoplastic feedstock is heated, extruded through a small nozzle, and deposited onto a surface to build 3D objects. Similar processes have been shown to have significant aerosol emissions in other studies using a range of plastic feedstocks, but mostly in industrial environments.
In this study, researchers measured ultrafine particle concentrations resulting from a popular commercially available desktop 3D printer using two different plastic feedstocks inside an office. Ultrafine particles (or UFPs) are small, nanosized particles less than 100 nanometers in diameter. Inhalation of UFPs may be important from a health perspective because they deposit efficiently in the lung and can even translocate to the brain. Estimates of emission rates of total UFPs in this study were high, ranging from about 20 billion particles per minute for a 3D printer utilizing a lower temperature polylactic acid (PLA) feedstock to about 200 billion particles per minute for the same type of 3D printer utilizing a higher temperature acrylonitrile butadiene styrene (ABS) feedstock.
The emission rates were similar to those measured in previous studies of several other devices and indoor activities, including cooking on a gas or electric stove, burning scented candles, operating laser printers, or even burning a cigarette."

Abstract of the research (

The development of low-cost desktop versions of three-dimensional (3D) printers has made these devices widely accessible for rapid prototyping and small-scale manufacturing in home and office settings. Many desktop 3D printers rely on heated thermoplastic extrusion and deposition, which is a process that has been shown to have significant aerosol emissions in industrial environments. However, we are not aware of any data on particle emissions from commercially available desktop 3D printers. Therefore, we report on measurements of size-resolved and total ultrafine particle (UFP) concentrations resulting from the operation of two types of commercially available desktop 3D printers inside a commercial office space. We also estimate size-resolved (11.5 nm to 116 nm) and total UFP (< 100 nm) emission rates and compare them to emission rates from other desktop devices and indoor activities known to emit fine and ultrafine particles. Estimates of emission rates of total UFPs were large, ranging from ∼2.0×1010 #/minute for a 3D printer utilizing a polylactic acid (PLA) feedstock to ∼1.9×1011 #/min for the same type of 3D printer utilizing a higher temperature acrylonitrile butadiene styrene (ABS) thermoplastic feedstock. Because most of these devices are currently sold as standalone devices without any exhaust ventilation or filtration accessories, results herein suggest caution should be used when operating in inadequately ventilated or unfiltered indoor environments. Additionally, these results suggest that more controlled experiments should be conducted to more fundamentally evaluate particle emissions from a wider arrange of desktop 3D printers.


In this work, we present some of the first known measurements of which we are aware of UFP emissions from commercially available desktop 3D printers. Emission rates of total UFPs were approximately an order of magnitude higher for 3D printers utilizing an ABS thermoplastic feedstock relative to a PLA feedstock: ∼1.9×1011 #/min compared to ∼2.0×1010 #/min. However, both can be characterized as “high emitters” of total UFPs. These results suggests caution should be used when operating some commercially available 3D printers in unvented or inadequately filtered indoor environments. Additionally, more controlled experiments should be conducted to more fundamentally evaluate aerosol emissions from a wider arrange of desktop 3D printers and feedstocks.

So, I think ventilation, fumes separation and/or extraction, insulated print chambers are the next things in 3d printers.


Looks like someone already had a similar idea, DIY fume cabinet for fumes extraction:


Update 2:

Instuctables on DIY testing of 3d printing safety:

They tested for different things and tests were negative. (HCN from ABS and Nylon).

Update 3:

One of the commentator (Thnx Allister) pointed on a project on Thingiverse:

Low cost Fume Chamber (Negative-Pressure, Activated Carbon Filtering) which does not require external exhaust.

Jul 20, 2013

HAGE3Dp-A2 3D printer with heat chamber

New printer coming from German special machining company. Main feature is closed heated print chamber. No exact dates on market release.


Print chamber: 610mm x 425mm x 300mm
Dimensions: 840mm x 650mm x 560mm
Print bed with continuous printing plate
Heat output of the print bed: approx 1000W
(Temperatures for ABS are easily accessible)
2 direct drive extruder (compact design)
Many times improved printing performance by a closed chamber
Preloaded XY drives via special belt backlash
Z axis with trapezoid thread spindles and maintenance-free light running nuts
Double doors in the front for easy removal of the print parts
Large viewing windows in the doors as well as in the side surfaces
Fully integrated control and media management
Power supply 230V + USB Data Connector

Jul 19, 2013

ProDesk3D update: printing at 25 microns

Looks great, but we will see how it works in real life ...

For video (embed doesn't work) , go to:

From update page:

Founders release FDM/PLA-based 25 micron mixed color printing video
Watch our gorgeous new video that demonstrates the beauty and finish quality of 25 micron printing, using our PLA filament. This video was taken with the ProDesk3D printing at 175 mm/s, with the video accelerated at certain points for the purpose of summarization. We also used this as another chance to preview our new translucent PLA colors, that we mixed to create the beautiful floral vase. Note that there are no lines to be seen due to the layer accuracy, just a gorgeous, smooth finish. The floral vase was printed exactly as offered, yet the ProDesk3D prints at a higher resolution than the original STL file!


High resolution DLP DIY 3D printer Instructables tutorial by Tristram Budel

Very deep and detailed tutorial on instructables how to build high resoultion DLP 3d printer. Kudos Tristram! It costs around 1750 euro in materials and took some 1500 (!?) hours to make.

Finished printer in enclosure. Enclosure is important since the UV sensible resin needs to be protected from the light.

Go to Instructables project page for very detailed assembly guide:



Dan Beaven made and blogged about his version based on this design:

Jul 17, 2013

3D printing with silkworms

Something completely different ...

From video description:

The Silk Pavilion explores the relationship between digital and biological fabrication on product and architectural scales.
The primary structure was created of 26 polygonal panels made of silk threads laid down by a CNC (Computer-Numerically Controlled) machine. Inspired by the silkworm's ability to generate a 3D cocoon out of a single multi-property silk thread (1km in length), the overall geometry of the pavilion was created using an algorithm that assigns a single continuous thread across patches providing various degrees of density.
Overall density variation was informed by the silkworm itself deployed as a biological "printer" in the creation of a secondary structure. A swarm of 6,500 silkworms was positioned at the bottom rim of the scaffold spinning flat non-woven silk patches as they locally reinforced the gaps across CNC-deposited silk fibers. Following their pupation stage the silkworms were removed. Resulting moths can produce 1.5 million eggs with the potential of constructing up to 250 additional pavilions.
Affected by spatial and environmental conditions including geometrical density as well as variation in natural light and heat, the silkworms were found to migrate to darker and denser areas. Desired light effects informed variations in material organization across the surface area of the structure. A season-specific sun path diagram mapping solar trajectories in space dictated the location, size and density of apertures within the structure in order to lock-in rays of natural light entering the pavilion from South and East elevations. The central oculus is located against the East elevation and may be used as a sun-clock.
Parallel basic research explored the use of silkworms as entities that can "compute" material organization based on external performance criteria. Specifically, we explored the formation of non-woven fiber structures generated by the silkworms as a computational schema for determining shape and material optimization of fiber-based surface structures.
Research and Design by the Mediated Matter Research Group at the MIT Media Lab in collaboration with Prof. Fiorenzo Omenetto (TUFTS University) and Dr. James Weaver (WYSS Institute, Harvard University). Mediated Matter researchers include Markus Kayser, Jared Laucks, Carlos David Gonzalez Uribe, Jorge Duro-Royo and Neri Oxman (Director).


Here is older post about 3d printing with bees:

How to 3d print models of molecules

Very extensive and detailed manual on instuctables that can guide you trough the process of finding, designing, software needed, exporting and working with 3d printed models of protein molecules.

Thanx theabion!


Here is detailed tutorial for Makerbots:

3D printed rollerblades

Jul 16, 2013

3D printed robot / armour boot

Ubercool looking 3d printed boots on instructables by jcpioneer!

I couldn't find any printfiles or more detailed design instructions. Hopefully the author will make it available.

UP plus 2

1749 USD
The ALL NEW UP! Plus 2 :
All the features of the UP Plus + More.  Auto-levelling, Auto-nozzle height calibration. 150 Micron printing, NEW multi-print function - let's you reprint models already stored in memory. ALL new Gen3 platform design with spring clips and super-hot platform (105'C).  Consistant ABS printing with the option for PLA!
Load your model - Click, click - PRINT!
Build Volume:              140mm(w), 140mm(d), 135mm(h)
                                     5-1/2"(w) x 5-1/2"(d) x 5-1/4"(h)
Z resolution:                 Settings 0.15mm / 0.20mm / 0.25mm / 0.30mm / 0.40mm
Print Head:                   Single head, single material, produces part as well as support material
Build Platform:              Heated - 105’C
Support Method:           Fully automated, simple, break-away. support material generation via software.
Workstation Compatibility: Windows XP, Vista & 7, MacOS
Overall Dimensions:      245mm(w), 260mm(d), 350mm(h)
                                      9-5/8"(w), 10-1/4"(d), 13-3/4"(h)
Weight:                          5Kg(11lbs)
Shipping Weight:         10Kg(22lbs)
Power input:                  100-240V, 50-60Hz,  220W
Connectivity:                  USB (internal memory SD flash storage on-board.
                                      Job can run independently of source computer once file has loaded.  NEW Multi-print feature!
What's in the Box?:        UP! Plus+ 3D Printer, power adapter, (0.7Kg)1.5lbs white ABS, 3 perfboards (gen4) & toolkit.
Heat & wind sheild
The heat/wind shield protects users from accidentally brushing up against the UP!'s "hot-end". The wind barrier re-directs air to cool the hot-thread as it is being extruded resulting in a finer finish.  Latest design allows for easy raft removal.
Low-cost, durable ABS material
The UP! uses ABS or PLA material in various colors.  Finished parts are solid & durable enough to be working parts.  Sand, machine and paint your objects to best suit your needs.
Solid metal construction.
The UP! Mini is built for printing speed & precision with it’s solid, all metal cconsturctions.  Each axis utilizes UP!’s solid metal linear bearing rail system that resists any torque during the printing process, resulting in the finest most precise parts in its class.
Ease of use.
the UP! comes with a fully-integrated,heated metal build platform which keeps your parts thermally stable thoughout the build cycle.  The newest platform comes with threaded, screw-down receivers that work with the UP!'s NEW perfboard build platform.  Along with the reliable, glass iBP system, the UP! has a great suite of build platform options to choose from.  UP! users now have the accessories at hand to get their designs to print exactly as they were intended.
Under the hood.
The UP! is controlled by the newest, most efficient mainboard to date.  It boasts integrated stepper motor controllers, integrated CPU and SD card and a full 20v rating to flawlessly provide power to all of the UP! working parts.
Smart support
No shape is too complex.  The UP! Mini utilizes the same automatic support generation that was first introduced with the UP! Start Plus+.  The Smart Support software works out where it requires support material and then prints it in a lower density in the same material. You simply break the support material off.  No need for dual-heads or dangerous soluble cleaning chemicals.
Price | Performance
The PP3DP is the overwhelming leader when it comes to Price | Performance in the market.  PP3DP has proven this with the success of their flagship,UP!  Plus+ 3D Printer and all-NEW UP! Mini.
What's in the box: UP! Plus 2, power adapter, 0.7kg ABS, 3 perfboards(gen3) and tool kit

Focus DIY powder 3d printer

Powder SLS DIY 3d printers are still in infancy. Focus project is trying to advance the area, but it is in early development stages with limited functionality.

Test print with nylon powder and carbon mixture

From project page:

Focus is a 3D printer that is designed to print using Selective Laser Sintering. Focus can also be adapted for FDM, 3DP and lasercutting/engraving.
Right now, Focus is a work in progress. I have been working on it since october last year. Since then a full design has been made. The printer and electronics have been built and a complete pack of firmware has been written. The firmware has been built from scratch because SLS and FDM just differ too much. The firmware handles normal FDM Gcode, and uses the E axis to determine if the laser has to be turned on or off.

Focus prints using a focusable 1500mw 808nm laser that sits on 2 axis. Both pistons move with a 64 step 1:64 geared stepper motor. The Gcode is stored on a SD card. The printer is stand alone and is controlled with a 4x20 LCD screen and 8 buttons. The printer is built using 3D printed parts and MDF.

The printer can be built for less than €600 (, or about $800), if you source the parts right.
(Edit, A rough parts list with prices for the printer have been added to the downloads)

Right now I only have engraved with the printer, but every system is about ready to start actual printing. I will post videos and pictures of this as soon as I have the process under control.

Laser cutting and engraving with Focus

Main project page:

Direction of this project changed to 3DP Inkjet Powder 3d printing

Update (21.8.2014.): 3DP model was further developed and released as mature machine called "Plan B":

3d printing with liquid metals at low temperatures

Metals used are exotic and I don't see the practical everyday purpose yet, but it looks cool. Drops are held by surface oxide layer. It can also create instant wire by applying air pressure and create contacts for electronic components.

extended cut 2 from Liquid Metals Guy on Vimeo.


3d printed ukulele and banjolele

3d printed ukulele (Makerlele)

3d printed banjo ukulele

Jul 14, 2013

eBay Exact

eBay also wants a piece of the 3d printing pie. They launched a mobile app (IOS) where you can  purchase and customize 3d printed objects. They have partnered with Sculpteo, MakerBot, and Hot Pop Factory. Nothing interesting to see here, move along.

Open Reflex 3D printable analogue camera

Video of shutter test:

Picture taken with it:

Detailed build instructions and files:

Spray for 3d printing: 3D LAC

At first I was thinking it was some sort of a joke. Then I realized that it makes some sense. Spray custom made for 3d printing: no perfume and more adhesion. Idea is to spray it on build platform and make objects stick to it better, which was sometimes done by applying regular commercial hair spray.

Web page seems to be under development without much information, but we will see will this product gain some traction or it is just vaporware (pun intended).


Here is a video of 3DLac spray in action:


Now there is a new spray product for enhanced adhesion to printebed called Dimafix.

3D Printed Bike Shifter

Jul 12, 2013

3D printing LEGO blocks

High precision is needed :-)! I expect some non-standard LEGO bricks soon!

Video by:

Setting up the PrintrBot LC

First part, I'll update this post as new show up ...

Update on solving most common printing errors:

Video by:

NASA successfully tests 3d printed rocket engine injector


NASA and Aerojet Rocketdyne recently finished testing a rocket engine injector made through additive manufacturing, or 3-D printing.
This space technology demonstration may lead to more efficient manufacturing of rocket engines, saving American companies time and money. The tests were conducted at NASA's Glenn Research Center in Cleveland.
The series of tests demonstrated the ability to design, manufacture and test a critical rocket engine component using selective laser melting manufacturing technology -- a method that employs high-powered laser beams to melt and fuse fine metallic powders into three dimensional structures.
"NASA recognizes that on Earth and potentially in space, additive manufacturing can be game-changing for new mission opportunities, significantly reducing production time and cost by 'printing' tools, engine parts or even entire spacecraft," said Michael Gazarik, NASA's associate administrator for space technology in Washington. "3-D manufacturing offers opportunities to optimize the fit, form and delivery systems of materials that will enable our space missions while directly benefiting American businesses here on Earth."
This type of injector manufactured with traditional processes would take more than a year to make, but with these new processes it can be produced in less than four months, with a 70 percent reduction in cost.
The project is supported by the Game Changing Technology Program in NASA's Space Technology Mission Directorate, which is innovating, developing, testing and flying hardware for use in NASA's future missions.

3d printed dog treat dispenser

3d printer+arduino+dog treats=happy dog. It works over internet too. Can the creator please open source it?


here is more developed 3d printed pet food dispenser and interaction PetBot:

Ultrasonic metal 3d printing

I just discovered this process ...

From video description:

The patented Ultrasonic Additive Manufacturing (UAM) process uses the power of sound to merge layers of metal foil. The process produces true metallurgical bonds with full density and works with a variety of metals such as aluminum, copper, stainless steel, and titanium. In combining additive and subtractive process capabilities, UAM can create deep slots, hollow, latticed, or honeycombed internal structures, and other complex geometries impossible with conventional subtractive manufacturing processes. Additionally, the solid state nature of the UAM bond allows for welding of dissimilar metals. This enables dissimilar metal cladding, production of custom metal matrix composites, and the ability to embed objects or sensors in a metal substrate. Through the use of UAM technology, customers will be able to manufacture complex parts that have unique features and attributes not possible using traditional manufacturing techniques. In addition, parts currently made with traditional operations can be made with much less waste, an increasingly important factor as more expensive, higher performance materials see broader use.

Company page:


Fabrisonic has a new BIG machine:

LegoBot 3d printer

It is a hot glue 3d printer. Made of LEGOs. Cool!

Jul 9, 2013

T8 - the 3d printed spider robot

T8 is a wirelessly controlled bio-inspired octopod robot made with high resolution 3D printed parts. It uses a total of 26 motors: 3 in each leg and 2 in the abdomen. It is powered by the Bigfoot™ Inverse Kinematics Engine which performs all of the necessary calculations for smoothly controlling the motions of the robot in real time.


Here is Spidey 3d printable DIY robot platform:

Video of home filastruder setup

GeoDroidJohn shows his filastruder setup. He uses PLA pellets and makes his own filament which drastically reduces material cost from $108 for 5 lbs to $7.

Slic3r Horizontal Shells tutorial on Top and Bottom Solid Layers

BusyBotz gives excellent overview of Slic3r horizontal shell functions.

RapidBot Mega 3d printer

From the product site:
RapidBot Mega is a fully working 3D Printer (build size 75x25x20 cm) .
RapidBot Mega comes standard with additional items such as: Kapton tapes, heated bed for PLA, power supply, USB cable, few meter PLA, Linear motion guide, flange Bearings, flange nut etc.
Technical Specification :
• Machine size 900 x 350 x 500 mm
• Build size 750x250x200 mm
• Nozzle Diameter : 0.4mm
• Layer Thickness : 0.1 mm
• Speed (mm/s) : 60
• Positionning Precision : 27 microns
• Input Format : STL
• Software : Pronterface
• System Copatibility : Windows 7 and Vista
• Power Supply : ATX, 450W
• Weight : 25 Kg
Features of Assembled RapidBot Mega 3D Printer

1. It uses high quality linear motion guide.
2. Compact Design.
3. Printrboard and Power Supply are placed at the bottom to give clean and neat look.
4. Mechanically more Stable design.
5. Improved the PrintBed Adjustment.
6. Improved Extruder Design and Z axis.
7. Accurate and easy belt placement.
8. Large build volume with easy accesibility.
9. Uses high quality acrylic 10. Integrated power supply for both Printrboard and Heatbed.
11. Uses high quality aluminium pulley with T2.5 belts, to give high accuracy.
12. Self locking design ensures rigid frame.

Assembled RapidBot Mega 3D Printer contains :

• Printrboard Electronics – with presoldered endstops with molex connectors and high temp heat cables for connecting Heater and Thermistor
• All hardware, bearings, bolts, nuts, washers, Linear motion guide, Flange Bearings, Flange nut etc
• All acrylic sheets (Side plates, Bottom plate, Top plate, Middle plate, Y frog support, Extruder base, Extruder motor plate, Heated printbed)
• M8 Threaded rods (296mm)
• Chrome plated Smooth rods (333mm)
• 5 Stepper Motors – with presoldered Molex connectors
• M4 Brass insert piece - for direct drive on motor shaft (5mm inner diameter)
• Pre-assembled J-Hotend, including G550 Thermistor, Heat Resistor, Cooling fan, etc
• Kapton tape 15mm (Insulation of Thermistor legs)
• Kapton tape 40mm (To print on)
• Set of 4 Heater blocks, 4 x 1.0 Ohm (for Heated printbed)
• Cooling paste (To use between Printbed and Heater blocks)
• PTFE strain-relief
• GT2 belts and pulleys
• Power Supply 450W, Input: AC 100-240V, 50-60Hz, 1.3A, Output: DC 12V, 37.5A
• USB and Power supply cables
• Extras such as Endstops, Magnetic leveler, Forceps, Few meter of PLA, Plastic tie etc.

Lead Time : 12 Days.
Delivery Time : 3-4 days after dispatch.
Price: 1250 USD

DIY 3D printed Swiss army knife scales

I found some interesting projects on Instructables. This one is about 3d printing custom scales for your Swiss army knife. You can make your DIY replacement scales for a standard SAK with some additional functionality. It's a sort of repair / upgrade swiss army knife hack.

Link with instructions and files:

Here is a different take on DIY 3d printed SAK scales for a smaller keychain model which look much better and probably gives a better grip:

MakiBox A6 first setup and print walkthrough video by Makible

Jul 3, 2013

3D printed fashion show shoes

OK, I'm going to say it: those are some VERY UGLY shoes. It's probably on everyone's mind. But they are 3d printed.

Ford Freeform Fabrication Technology (F3T), 3d printing with sheets of metal

Ford developed new prototyping technology. It makes 3d prototypes from sheets of metal using robotic hands. Looks cool and it will probably be standard full production technology one day.

Two pressure heads moved via robotic hands shape the model from two sides.

The technology is not new, probably only the implementation and new machinery is developed.

Rapid Prototyping of Sheet Metal Components with Incremental Sheet Forming Technology, thesis by Meelis Pohlak
