Nov 30, 2012
Objet desktop professional 3d printers
Sinterhab - 3d printed lunar module
SinterHab
From the site:
This project describes a design study for a core module on a NASA Lunar South Pole outpost, constructed by 3D printing technology with the use of in-situ resources and equipped with a bio-regenerative life support system. The module would be a hybrid of deployable (CLASS II) and in-situ built (CLASS III) structures. It would combine deployable membrane structures and pre-integrated rigid elements with a sintered regolith shell for enhanced radiation and micrometeorite shielding. The closed loop ecological system would support a sustainable presence on the Moon with particular focus on research activities.
The construction method for SinterHab is based on 3D printing by sintering of the lunar regolith. Sinterator robotics 3D printing technology proposed by NASA JPL enables construction of future generations of large lunar settlements with little imported material and the use of solar energy. The regolith is processed, placed and sintered by a the Sinterator robotics system which combines the NASA ATHLETE and the Chariot remotely controlled rovers. Microwave sintering creates a rigid structure in the form of walls, vaults and other architectural elements. The interior is coated with a layer of inflatable membranes inspired by the TransHab project.
WSU scientists develop 3d printing from Moon dust
Chopper - Princeton's framework for partitioning 3d printing models
Abstract from the project site:
3D printing technology is rapidly maturing and becoming ubiquitous. One of the remaining obstacles to wide-scale adoption is that the object to be printed must fit into the working volume of the 3D printer. We propose a framework, called Chopper, to decompose a large 3D object into smaller parts so that each part fits into the printing volume. These parts can then be assembled to form the original object. We formulate a number of desirable criteria for the partition, including assemblability, having few components, unobtrusiveness of the seams, and structural soundness. Chopper optimizes these criteria and generates a partition either automatically or with user guidance. Our prototype outputs the final decomposed parts with customized connectors on the interfaces. We demonstrate the effectiveness of Chopper on a variety of non-trivial real-world objects.You can find the paper, video and more details on:
http://gfx.cs.princeton.edu/pubs/Luo_2012_CPM/index.php
Nov 29, 2012
High end 3D printed fasteners
3d printing ceramics
They are fundraising to develop the technology further. I hope they make it. Their campaign: http://search.voltcrowd.com/campaign/detail/554
From the campaign page:
Quick PitchFigulo 3D prints ceramics for consumers, artists and businesses. We are revolutionizing the design and production of ceramic objects.Who We AreFigulo Corporation is a manufacturer of custom designed ceramics made using advanced materials and 3D printing technology.Our Vision & Lightbulb MomentI was at an engineering conference and an artist spoke about the difficulty of realizing her digital art. I realized that we could do this using 3D printing.Our Product/Service, The Problem We're SolvingFigulo changes the design parameters for ceramics and frees the designer from the constraints of the mold and potters wheel. We have developed a unique 3d printing technology that redefines the way that ceramics are made. We open the world of ceramics to anyone with a computer, a design and access to the internet.What We've Done So FarWe have created a 3D printing manufacturing facility in South Boston where we print, fire and glaze ceramic objects for customers all over the world. We have a staff of dedicated 3D printing experts and ceramic artists, where we work at the intersection of engineering and art.Our Business Model - How We Make MoneyWe manufacture uniquely designed, functional, decorative, custom ceramic objects from our own collection and from files uploaded to our website and other channels. We sell these designs directly to consumers and businesses.Why We're Raising FundsWe are raising funds to expand our marketing efforts and outreach to consumers and develop next generation of the 3D printing manufacturing process.
Nov 28, 2012
Preview of Rostock MAX RAMBo controller with LCD
Multi colored RepRap Mendel printing
RepRapPro Multi-material Printing from Adrian Bowyer on Vimeo.
http://reprappro.com/Special_Blog?cmd=post&id=12
Voxeljet VX4000 - industrial 3D printer for sand casting
Objet 1000
From the sales pitch:
The Objet1000 is Objet's largest ever 3D printer. With a build platform of 1000 x 800 x 500 mm (39 x 31 x 20 inch), the system enables designers, engineers and manufacturers to quickly and easily create large and very precise models for prototyping parts and products in automotive, defense, aerospace, consumer goods, household appliances and industrial machinery sectors. The system features Objet Connex multi-material technology offering standard and ABS plastic performance, a choice of over 100 materials and the ability to mix up to 14 different materials in a single prototype or model to achieve the true look, feel and function of your intended end product.
http://objet.com/3d-printers/connex/objet1000
Prusa Nozzle - new full metal 3d printing nozzle
- No PTFE or PEEK (can't be molten)
- Food safe Stainless Steel
- Using powerful heat cartridge
- Prints ABS and PLA
- Ready to print Polycarbonate, PEEK & Nylon[1]
- Easy to mount (M6 thread)
- Open Source once ready to sell
- Made by designer of Prusa Mendel
- 70€ fully assembled including nozzle, heater block with heater cartridge and thermistor, wade compatible ALU mount plate.
http://prusanozzle.org/index.html
Nov 27, 2012
Ultimaker print farm
Printrbot Jr. Videos
Rest of the videos in on: http://www.youtube.com/user/printrbot/
Printrbot Jr. 3d printing on batter power:
Printrbot Jr. - Your kid's first printer
The Printrbot jr. - TWO Printrbot jr. kits for $700. Keep one for yourself. GIVE one to a local school.
- Small. Folds up and fits in a backpack.
- Tiny Footprint. Sits easily on a desk.
- Light. 6 lbs. PLA. Uses biodegradable, non-toxic plastic.
- Batteries optional. Ships with off the shelf 12V power supply.
- Simple to build and operate.
WASP printer / mill video presentation
Test your models online with www.willit3dprint.com
So what can Willit 3D Print do?:
- Test if your part has features that can be 3D printed or not
- Visualise the surface roughness of the printed part
- See where support is needed
- Estimate the build time and the cost of your part
- Calculate the carbon footprint of your part
- Reorientate, rescale, and reposition your part
- Export your changes (in STL or AMF)
http://www.willit3dprint.com/
Update: I gave it a short test. In my latest version of Firefox it failed to load file, probably a bug on my side. It works perfectly in Chrome. It still needs more simulated printers and print materials. Great tool!
New printer prototype - Delta Forge
More details and video: http://delta-forge.com/category/blog
Nov 26, 2012
New 3d printer - Prusa AL
Tech specs:
- Build envelope(mm): PrusAL - 200mmX200mmX250mm (with RepRap Pro bowden)
- PrusAL - 200mmX200mmX210mm (with classic extruder)
- Technology: FFF
- Nozzle diameter (mm): 0.35 mm
- Layer thickness (mm): <0.05 mm
- Speed (mm/s): standard 100mm/s - 300mm/s - rigid construction mechanics and hardware can support even faster speeds but expect some loss in print quality)
- Positioning precision: <0.1 mm
- Electronics: RAMPS
- Software: Rapcraft software bundle compatible with open source RepRap
- System compatibility: Windows / MAC / Linux
- Compatible print materials: ABS, PLA
- Weight: 16,5 LBS (7.8 KG)
- Power Supply: 12V International plug ready external
- Price: $1,555 for DIY kit, $1,700 for PrusAL with classic wade extruder fully assembled, $1,777 for PrusAL with bowden fully assembled
Ultimate guide to 3D printing - summary
-Afinia H-Series – Best Overall Experience, Easiest Setup & Easiest to Use (tie)-Bukobot 8 - Most Innovative & Most Accurate (Runner-Up)-Cube - Most Reliable, Easiest to Use (Tie) & Best Documentation (Tie)-Lulzbot AO-100 – Best Documentation (Tie) & Fastest (Runner-Up)-Printrbot LC – Best in Class (Entry Level)-Printrbot Jr. – Best Value-Replicator 2 – Best in Class (Premium) & Most Accurate (Runner-Up)-Solidoodle 2 – Best Value (Runner-Up)-Type A Series 1 – Best in Class (Midrange), Most Accurate (Runner-Up)-Ultimaker - Best Open Hardware, Most Accurate & Fastest
Video demo of Rostock MAX z axis speed
Nov 25, 2012
Ultimaker controlled with inbuilt tablet PC
Full story and more details on: http://communities.ossoil.com/2361/diy-ulticontroller-mounted-wetab-on-ultimaker/
New low-cost 3d printer: Portabee
From the product page:
The Portabee has been the first conveniently portable 3D printer in the world. It is easily collapsible in a matter of seconds and fits into a laptop bag, making it transportable 'on-the-go' - bring it along with you when taking a bus, a train... even on a bicycle in a haversack on your back! And since it's lightweight - weighing in at 2.8kg (6.2lbs) - you can bring it around anywhere with you!
And with a slightly larger 'laptop luggage' style bag, you can put the Portabee into the same bag as your laptop computer, along with some feedstock filament, power supplies for both devices (the Portabee uses a laptop-type power supply), some instant coffee sachets, cookies... you get the idea.
The Portabee opens up numerous possibilities which were previously impractical - designers and design engineers can now offer to print out a sample of their design solution at the client's premises, on the spot and with applied design changes, for quick evaluation. Educators can loan Portabees to students for a time period to complete a school assignment involving 3D printing, be it an arts, design, or engineering discipline. An artist can walk into her favourite cafe, suddenly get in a creative mood, whip out the Portabee and a laptop and start designing something and print it out, all while sipping her usual cuppa and enjoying some cheesecake.
The Portabee is available as an unassembled kit form with a colour illustrated step-by-step assembly guide. Assembled and tested Portabee 3D Printers are also available.
- 135x135x120mm build volume
T2.5New! 2GT (GT2) belts and machined pulleys- Full linear bearings on all axes
- All stainless steel hardware where applicable, hardened steel linear rods (smooth rods)
- Single board solution Gen6.d electronics with integrated fan and SD card support
- Heated platform (printbed) included as standard
- Uses common, tried and tested Ø 3mm* feedstock filament, commonly PLA and ABS materials
- 0.5mm standard nozzle*
http://romscraj.com/carttoo/index.php?route=product/product&product_id=122
They also provide files for printing of support elements.
3D model surface restoration
Nov 24, 2012
High-end 3d metal printing
Direct Metal Laser Sintering - DMLS
(with some nice engineering nerdy humor)
Rapid Prototyping and Digital Sand Casting
Nov 23, 2012
New diy 3d printer - miniFactory
Specs are:
- Build area: 140 x 150 x 140 mm or 5.5 x 5.9 x 5.5 inches
- Layer thickness: 0.1 - 0.3 mm with miniFactory™ original nozzle
- Speed: Up to 80 mm/s
- Nozzle diameter: 0.35 mm
- Positioning precision: 0.0004 mm on Z axis and 0.016 mm on XY axes
- Material: 1.75mm PLA
- Printer dimensions: 42.0 (L) 33.5 (W) 33.5 (H) cm
- Printer weight: <10 kilograms
- Electronics: 4 Stepper motor controllers, 2 temperature sensors, end-stop switches for XYZ axes, 2 heater outputs, 1 extra output for example fan controlling
- Price: EUR790 / USD1,010 / GBP635 (not included taxes and shipping costs)
Nov 21, 2012
DIY volumetric 3d display for 40 euro
Via Hackaday
Update:
Michele has a new version of this 3d display that is combined with a projector:
Details can be found at:
http://volumetrics.co/
Nov 19, 2012
Comparison of MakerBot Replicator, LulzBot AO-100 and Uprint SE Plus
Working 3D Printed Automatic Transmission Gear system
From the video description:
This is an automatic transmission model I designed and 3D printed (you can download the design here: http://www.thingiverse.com/thing:34778). This type of gearing arrangement is common in automatic transmissions in cars, though the clutches and brakes and hydraulics that control them are far more complex than modeled here. Also missing is the torque converter.
These gears are known as herringbone, which are not generally found in real transmissions because they are too difficult to machine. However, they are easy to print, and they have the advantage of being self-centering.
Nov 13, 2012
Mixing 3d printed and real objects
A sandstone block built from lego, blending real objects with 3d prints from Greg Petchkovsky on Vimeo.
Made for the "Make it real" challenge on Instructables, http://www.instructables.com/contest/makeitreal/?show=INFO
Nov 12, 2012
Silent Runner blimp with 3d printed parts
http://www.silent-runner.net/index.php/Main_Page
http://www.thingiverse.com/thing:31180
Metal casting in 3d printed mold
http://www.thingiverse.com/thing:26500
Nov 11, 2012
3d printing furniture out of recycled waste plastic
Untitled from Dirk Vander Kooij on Vimeo.
Pensa DIWire Bender - 2d and 3d metal wire shapes
The DIWire Bender from PENSA! on Vimeo.
The DIWire Bender is a rapid prototype machine that bends metal wire to produce 2D or 3D shapes.
Wire unwinds from a spool, passes through a series of wheels that straighten it, and then feeds through the bending head, which moves around in 3 dimensions to create the desired bends and curves. Vector files (e.g., Adobe Illustrator files), text files of commands (e.g., feed 50 mm, bend 90° to right…) provide DIWire’s instructions.
It’s essentially a 3D printer that describes lines, instead of volumes, in space, and it could be used for anything from prototypes to customized products.
Dremelfuge
http://www.thingiverse.com/thing:1483
Update (26.3.2014.):
Here is interview with the creator and more details on field use:
http://diy3dprinting.blogspot.com/2014/03/3d-printable-dremelfuge-and-revolution.html
Nov 10, 2012
3d printed purse - Zip Top Bag
It is 3d printed bendable purse/container/wallet/pen box. You print out the parts and assemble them in few simple steps. I think I'll print one out for my girlfriend
http://www.thingiverse.com/thing:33765
Nov 7, 2012
3d printing with your mind
http://www.thinkerthing.com/
They are using Emotive EPOC headset (299$) which is a high resolution, neuro-signal acquisition and processing wireless neuroheadset.
Nov 6, 2012
New 3d printer - L5
Printing a 3d pumpkin:
http://www.youtube.com/watch?v=3dpdy0zwhPc
Main features from their Kickstarter page:
Injection-Molded Plastic PartsMore on:
All of the molded parts have molded-in inserts that eliminate a lot of complication and extra hardware (no nuts to tighten!). This allows the printer to be assembled quickly and provide consistency in manufacturing, making your printer more accurate.
New Head Design
We have taken components that we have liked from other designs and combined them to create our complete head design. The cold end and the hot end combine to make a functioning and simple to put together head.
X-Axis Movement
A gear on rack design controls the movement in the x-axis; this means there are no belts or pulleys, simplifying the assembly as well as eliminating calibration.
Y-Axis Movement
A uniquely designed motor mount allows both sides of the motor to control movement in the Y-Axis. This ensures that the build tray will move evenly back and forth.
Z-Axis Movement
We use ACME threaded rods and screws with two nema 17 motors wired in parallel. One of the challenges is getting the Z-Axis to home to the build tray at the right level. We have designed a special clip that snaps onto the Z-Axis rod, which fixes this problem making it simple to calibrate.
Heated Build Tray
With a heated build tray, you can build PLA or ABS plastic without warping. It is very easy to level with four screws, one on each corner. Together with easy leveling and the Z-Axis clip you can have your build tray homed and leveled without getting frustrated.
Snap-in Roller Bearings
The L5 printer uses 12 roller bearings to give it the smoothest movement in the X Y and Z-axis.
Great Design
We wanted a printer that not only prints well, but also looks great. A printer that would be a conversation piece that looked good on an office desk, in your home or at school. We went through many design iterations until we found a design we felt was clean and simple. A design that was inspired by speedboats and sexy cars.
http://www.kickstarter.com/projects/1650950769/l5-3d-a-stylish-and-affordable-3d-printer
Uformia MeshUp 3d mashup for meshes software
Advanced 3d models manipulation, merging and design software from Uformia. More on:
http://www.kickstarter.com/projects/723819776/meshup-mashup-for-meshes
http://uformia.com/
Update:
here is Uformia on 3d Printshow in NYC, 2014:
Nov 5, 2012
DIY 3d printing news and news bits 05-11-2012
Kickstarter campaign for affordable 3-D printer "Pandabot" put on hold by founders.
http://www.wired.com/design/2012/10/pandabot-cancelled/With ‘Safe Haven,’ Desktop Weaponeers Resume Work on 3D-Printed Guns
http://www.wired.com/dangerroom/2012/10/wiki-weapon/Personal 3-D Printer Sales Jump 35,000% Since 2007
http://www.bloomberg.com/news/2012-10-24/personal-3-d-printer-sales-jump-35-000-since-2007.htmlWASP 3d printer and some interesting models seen in public:
3D printing 4th dimension
3d printed puzzle that represents four dimensional space shapes. I don't have a slightest clue how to explain it, but maybe some of you can figure it out.
More detailed text on: http://blogs.scientificamerican.com/observations/2012/10/31/mathematicians-at-play-3-d-puzzl/
3d printing featured in Dilbert
Source and copyright owner: http://dilbert.com/strips/comic/2012-11-05/ Update, new Dilbert comic:
http://diy3dprinting.blogspot.com/2014/03/wally-and-3d-printer-testing.html
Nov 1, 2012
Video of Printrbot speed build
Video description is:
Printrbot featuring my minimal direct drive extruder and xbox power supply!
Whosawhatsis' MK7 replacement: http://www.thingiverse.com/thing:15718
My extruder carriage: http://www.thingiverse.com/thing:29146
Toggle switch holder: http://www.thingiverse.com/thing:29497
Two part printrbot base for easy printing: http://www.thingiverse.com/thing:26266
